Gas Detector » Gas Detector
Gas Detector

The GSEC Gas detector model

PG series provide the user with the feature needed to detect LPG, CNG, Butane, Hydrogen and Ethanol. The detector utilized for LPG, CNG, Butane, Hydrogen and Ethanol. GSEC Gas detector model PG series provides accurate detect of gas. Proven detector design matched with reliable state-of-the-art electronics results in the ideal complete package to protect your plant and personnel.

Specification

Enclosure :Fire retardant
Operating temp : +32oF to 113oF (0oC to 45oC)
Output signal :Output signal available with no relay needed because it may cause spark.
Response time : 5 sec
Indicator : Built-in buzzer and LED
Gas detected : LPG at 0.06%-1.00%, CNG at 0.06%-1.00% and other gases such as Butane, Hydrogen and Ethanol.

Gas Detector

Technical Data

Description
PG-601AC
PG-602DC
Input
AC 220V/50 Hz
12 VDC
Output
12 VDC
12 VDC
Power (w)
3
3
Target Gases
LPG, CNG, Butane, Hydrogen, Ethanol
LPG, CNG, Butane, Hydrogen, Ethanol
Response time
5 sec
5 sec
Detection range
500-10000 ppm
500-10000 ppm
Operating temp. / %RH
-20oC to 40oC/95%
-20oC to 40oC/95%
Audible alarm (Buzzer), LED
Available
Available


Gas Detector (ForFire Alarm)

Technical Data
Specification Gas Detector MODEL PG-603NO, PG-605NO

1. ǨѺʠ LPG (0.06 1.00 %), CNG (0.06 1.00 %)
2. § ALARM ͵ǨѺ
3. Contact Relay




GAS DETECTOR
MODEL
PG-603NO
PG-605NO
Alarm Output
1 N0. Contact
1 N0. Contact
Alarm LED
Green
Green
Alarm buzzer
Orange
Orange
LPG
70 dB
70 dB
CNG
YES
YES
Hydrogen
YES
YES
Ethanol
YES
YES
Gas concentration
0.06 1.00 %
0.06 1.00 %
Operating temp. & hum.
-20 ~ 40C Max 90%RH
-20 ~ 40C Max 90%RH
Power supply
24VAC
220VAC
Power consumption
1.5 W
1.5 W
Dimension
70x110x34
70x110x34
Weight
220 g.
220 g.
Color
Cream
Cream
